Yamaha Electric Controller Replacements
Welcome to D&D Motor Systems, the last manufacturer of golf cart parts in the USA, with over 95% of our DC motor components made domestically. We offer the broadest range of high-performance Yamaha electric motors and Yamaha golf cart parts globally. Our unique motor selection tool asks key questions about your Yamaha Precedent motor, calculates maximum current draw and thermal needs, and provides safe, high quality, and affordable options for Yamaha motor upgrades, including Yamaha high speed motors and Yamaha electric motor upgrades—all in stock.
Made in The USA
Only Golf cart Electric motors and controllers made in the US."If it ain't blue, it aint red, white and blue"
Fast, Reliable Shipping
Shortest leadtimes in the industry. 96% of our high performance golf cart products ship within 24 Hours.
Competitive Pricing
Best prices Made in the USA. Find a similar product cheaper? We'll match it!
Use our Custom Motor Tool for $30 off
Choose a Motor tailored for your needs!
Stock
300 Amp
$555
14 MPH
5% Torque
Speed
400 Amp
$610
20-22 MPH
20% Torque
Speed
440 Amp
$649
20-22 MPH
20% Torque
Torque & Speed
500 Amp
$723
14 MPH
30% Torque
Torque & Speed
600 Amp
$749
14 MPH
30% Torque
Regen VS Series Cart
5 Key differences (Use 3-5 to confirm your type)
1.If the golf cart has a Tow/Run or Run/Maintenance switch under the seat, it's a Regen (Regenerative Braking) cart. If not, it's a Series cart (except Club Car Regen I models).
See examples below (Fig. 1.1, Fig. 1.2 & Fig. 1.3).
Fig 1.1
EZGO
Run/Maintenance Switch
Fig 1.2
Club Car
Tow/Run Switch
Fig 1.3
Yamaha
Tow/Run Switch
2.If the motor has a speed sensor wire, it's a Regen motor. If not, it's a Series motor.
EZGO Regen Motor
Club Car Regen Motor
3.What do the motor Field Coil Windings Look Like?
- Regen motors: Have "shunt" or "round wire" coils, typically with smaller wire (12AWG - 24AWG), and many turns (60–200+ per coil).
- Series motors: Have "flat wire" coils, with larger, rectangular wire and fewer turns (5–15 per coil).
See Fig. 3a & 3b below
Fig. 3a
Regen
Round/Shunt field coils
Fig. 3b
Series
Flat Filed Coils
4.If the motor has 2 smaller (1/4-20 UNC) and 2 larger (5/16-18 UNC) terminals, it's a Regen motor. If all 4 terminals are the same size (5/16-18 UNC), it's a Series motor.
5.Series Vehicle Features
EZGO Series Cart Features
(Except Regen DCS EZ-GO Model, which HAS this handle.)
1st Generation:
1204 or 1205 footprint. Marathon Models mainly. (YR. 1990-1994.5)
2nd Generation:
1206 footprint. TXT Models mainly.(YR. 1994.5 & Up)
Club Car Series Cart Features
Black Controller:
Throttle (0-5k): 36 Volt(YR. 1990-1994)
Silver Controller:
Throttle (0-5k): 36 Volt(YR. 1990-1994)
